Generating TIFF files on an Android device

I recently built an app with some very specific and unusual requirements. Amongst other things, here's what it had to do:

• Capture RAW image data from the camera lens on a specific mobile phone in a rapid-fire burst. The goal was to capture as much data as possible as rapidly as possible.
• The camera must be set up to take consistent photos under controlled lighting conditions. Autofocus and white balance adjustments must be disabled
• The app must run entirely offline, with no internet connection available at the point of use
• Output must be a multi-frame TIFF file with no data loss.

It was that last requirement that threw up an unexpected challenge!

The problem with TIFF on Android

Android has no native TIFF support. There is no built-in encoder in the SDK, so you're reliant on third-party libraries, and I just couldn't find one!

So I did what any engineer does when the libraries let them down: I read the spec...the TIFF file spec from 1992, no less!

Writing a TIFF encoder from scratch

The TIFF 6.0 specification is intimidating at first but actually turns out to be a very well-structured document. A TIFF file is structured as:

1. An 8-byte header, establishing byte order, a magic number (42 - don't know why), and the offset to the first IFD (Image File Directory)
2. A series of IFDs, one per frame, each containing an ordered list of tagged entries describing that frame's metadata and a pointer to the next IFD
3. The raw image data for each frame

For a multi-frame file like ours, the IFDs form a linked list through the file. The last one simply writes 0 as its next-IFD offset to signal the end.

The header itself is just 8 bytes:

fun writeHeader(out: OutputStream) {
    val header = ByteArray(8)
    header[0] = 73 // "II" - Intel byte order (little-endian)
    header[1] = 73
    header[2] = 42 // magic number
    header[3] = 0
    header[4] = 8  // offset to first IFD (immediately after this header)
    header[5] = 0
    header[6] = 0
    header[7] = 0
    out.write(header)
}

Simple enough. It's everything after that gets interesting.

The trickiest part of the implementation wasn't any individual piece. It was computing all the byte offsets correctly. Each IFD needs to know exactly where its image data starts in the final file, which depends on the accumulated size of every IFD and image block that precedes it.

// Offset arithmetic for a given frame
val ifdDataSoFar   = (frameNumber + 1) * ifdByteSize
val imageDataSoFar = frameNumber * imageSizeBytes
val doubleDataSoFar = (frameNumber + 1) * (numberOfBytesInDouble * doubleIfdEntries.size)

val imageStartsAt = headerSize + ifdDataSoFar + imageDataSoFar + doubleDataSoFar

The other bump in the road was that IFD entries can only hold 4 bytes of value data inline. For Double values (used to embed per-frame metadata like exposure time), you write an offset pointer in the entry itself and stash the actual value at the end of the IFD block. I used a small interface hierarchy to handle this:

interface IIfdEntry {
    val key: Int
    val fieldType: Int
    val count: Int
    val value: Number
}

IntIfdEntry writes its value inline. DoubleIfdEntry triggers the offset-pointer pattern. The encoder collects all double entries during IFD construction, then writes their values after the IFD entries and before the image data.

Each IFD is built from a standard set of tags, with extra ones passed in per-frame:

val ifdEntries: MutableList<IIfdEntry> = mutableListOf(
    IntIfdEntry(TIFF_Tag_ImageWidth,                TIFF_FieldType_Long,  1, width),
    IntIfdEntry(TIFF_Tag_ImageLength,               TIFF_FieldType_Long,  1, height),
    IntIfdEntry(TIFF_Tag_BitsPerSample,             TIFF_FieldType_Short, 1, 16), // RAW = 16-bit
    IntIfdEntry(TIFF_Tag_Compression,               TIFF_FieldType_Short, 1, 1),  // no compression
    IntIfdEntry(TIFF_Tag_PhotometricInterpretation, TIFF_FieldType_Short, 1, 1),  // BlackIsZero
    IntIfdEntry(TIFF_Tag_SamplesPerPixel,           TIFF_FieldType_Short, 1, 1),
    IntIfdEntry(TIFF_Tag_RowsPerStrip,              TIFF_FieldType_Long,  1, height),
    IntIfdEntry(TIFF_Tag_StripByteCounts,           TIFF_FieldType_Long,  1, imageSizeBytes)
)
ifdEntries.addAll(extraEntries)
ifdEntries.sortBy { it.key } // spec requires ascending order

The TIFF spec also reserves tag IDs above 32768 for private use, which I took advantage of to embed per-frame capture metadata (capture time, exposure time and ISO speed) directly inside the file, alongside the standard tags.

The result

Here's how it's used in practice:

val encoder = SimpleTiffEncoder(width, height)
encoder.writeHeader(outputStream)

frames.forEachIndexed { index, frame ->
    encoder.writeTiffPage(outputStream, frame.metadata, frame.pixels, index, frames.size)
}

One call to writeHeader, then one call to writeTiffPage per frame. The output is a valid multi-frame, 16-bit TIFF with embedded capture metadata. No dependencies required.

(Some code has been left out for readability - just wanted to give you the flavour of the implementation!)
